Mid Drive Unit
With our Mid Drive Unit you have the perfect companion for demanding terrain, where it depends on agility, good dosage and a power applied in the right situation. The X700 develops great power, combined with a very sensitive sensor technology, which gives you security and control on the trail.
- The controller has high matching degree with the motor, very stable performance and high reliability.
- The core algorithm of riding is self-developed, also tested in practice through countless test procedures in the machine as well as on the trail.
- The riding response is sensitive, which comes very close to a natural driving experience
- The built-in magnetic steel design enables the MIVICE motor to provide higher power output
| Model NO. | X700 Mid Drive Unit | |
|---|---|---|
| Rated Voltage (DC V) | 36 | 48 |
| Rated Power (W) | Optional（250-500） | Optional（250-500） |
| Dimensions | 223×154×141 | 223×154×141 |
| Weight (kg) | 3,6 | 3,6 |
| Motor Position | MID | MID |
| Way Out | Terminal Block Outlet | Terminal Block Outlet |
| Wheel Size | 2Optional | Optional |
| CL (mm) | 53 | 53 |
| System Efficiency | ≥80% | ≥80% |
| Max Torque (Nm) | ≥100 | ≥110 |
| No load Speed (rpm) | 110±5 % | 115±5 % |
| Rated Speed (rpm) | 97±5%（500W） | 104±5%（500W） |
| Reduction Ratio | 36 | 36 |
| Noise (dBA) L=1m | ﹤65 | ﹤65 |
| transmission | Gear Drive | Gear Drive |
| Shaft Standard | ISIS | ISIS |
| Crankset (Recommended) | 38T | 38T |
| Sensor | Cadence and Torque Integrated | Cadence and Torque Integrated |
| Front/Rear lights | DC12V / 6W | DC12V / 6W |
| Feature Options | Brake sensor（POWER OFF） Shift sensor（POWER OFF） | Brake sensor（POWER OFF） Shift sensor（POWER OFF） |
| Operating temperature (°C) | -20°C~45°C | -20°C~45°C |
| IP Rating | IP65 | IP65 |
| Certification | EN 15194/ROHS | EN 15194/ROHS |
Therefore MIVICE-eBike-Parts
Our mission is to turn our passion for biking into products - giving everyone in the world the opportunity to positively experience the MIVICE product that is right for them. We do not only develop products theoretically - we also test and try our components intensively ourselves on the roads, trails or gravel paths. The experience of both drives us to develop and produce the best possible product for you.
